Bootstrap Responsive ASPNet Menu control for Mobile Phone Tablet and Desktop display

In this article I will explain with an example, how to build a Database driven Twitter Bootstrap Responsive ASP.Net Menu control i.e. ASP.Net Menu control that works for Mobile Phone, Tablet and Desktop displays.

The ASP.Net Menu control items will be dynamically populated from database using C# and VB.Net.

Database

I have made use of the following table Menus with the schema as follows.

Bootstrap Responsive ASP.Net Menu control for Mobile Phone, Tablet and Desktop display

I have already inserted few records in the table.

Note: You can have as many child levels as you want, here I am using 2 Level Menu structure.

Home => Home.aspx

Services

Consulting => Consulting.aspx

Outsourcing => Outsourcing.aspx

About => About.aspx

Contact => Contact.aspx

Note: You can download the database table SQL by clicking the download link below.

Download SQL file

HTML Markup

Below is the HTML Markup of the Master Page Main.Master containing inherited Bootstrap and jQuery files and an ASP.Net Menu control.

The Menu control is placed inside the Bootstrap Menu and its following properties are set in order to make it Responsive.

1. Orientation – Horizontal.

2. RenderingMode – List. This makes the menu render as an HTML List.

3. StaticMenuStyle-CssClass – The Bootstrap classes i.e. nav and navbar-nav are set.

4. DynamicMenuStyle-CssClass – The Bootstrap class dropdown-menu is set.

media="screen" />

<button type="button" class="navbar-toggle collapsed" data-toggle="collapse" data-target="#bs-example-navbar-collapse-1"

aria-expanded="false">

<span class="sr-only">Toggle navigation</span> <span class="icon-bar"></span><span

class="icon-bar"></span><span class="icon-bar"></span>

</button>

<a class="navbar-brand" href="#">ASPSnippets</a>

</div>

<asp:Menu ID="Menu1" runat="server" Orientation="Horizontal" RenderingMode="List"

IncludeStyleBlock="false" StaticMenuStyle-CssClass="nav navbar-nav" DynamicMenuStyle-CssClass="dropdown-menu">

</asp:Menu>

</div>

Namespaces

You will need to import the following namespaces.

using System.IO;

using System.Data;

using System.Data.SqlClient;

using System.Configuration;

VB.Net

Imports System.IO

Imports System.Data

Imports System.Data.SqlClient

Imports System.Configuration

Populating the ASP.Net Menu control items from database

The PopulateMenu method is a recursive function. Inside the Page Load event of the Master Page, the Menu control is populated with the records from the Menus table.

Inside the PopulateMenu method, a loop is executed over the DataTable and if the ParentMenuId is 0 i.e. the menu is a parent (root) menu, again a query is executed over the Menus table to populate the corresponding submenus and again the PopulateMenu method is called.

This process continues until all menus along with their submenus are added to the ASP.Net Menu control.

protected void Page_Load(object sender, EventArgs e)

{

if (!this.IsPostBack)

{

DataTable dt = this.GetData(0);

PopulateMenu(dt, 0, null);

}

private DataTable GetData(int parentMenuId)

{

string query = "SELECT [MenuId], [Title], [Description], [Url] FROM [Menus] WHERE ParentMenuId = @ParentMenuId";

string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;

using (SqlConnection con = new SqlConnection(constr))

{

DataTable dt = new DataTable();

using (SqlCommand cmd = new SqlCommand(query))

{

using (SqlDataAdapter sda = new SqlDataAdapter())

{

cmd.Parameters.AddWithValue("@ParentMenuId", parentMenuId);

cmd.CommandType = CommandType.Text;

cmd.Connection = con;

sda.SelectCommand = cmd;

sda.Fill(dt);

}

return dt;

}

private void PopulateMenu(DataTable dt, int parentMenuId, MenuItem parentMenuItem)

{

string currentPage = Path.GetFileName(Request.Url.AbsolutePath);

foreach (DataRow row in dt.Rows)

{

MenuItem menuItem = new MenuItem

{

Value = row["MenuId"].ToString(),

Text = row["Title"].ToString(),

NavigateUrl = row["Url"].ToString(),

Selected = row["Url"].ToString().EndsWith(currentPage, StringComparison.CurrentCultureIgnoreCase)

};

if (parentMenuId == 0)

{

Menu1.Items.Add(menuItem);

DataTable dtChild = this.GetData(int.Parse(menuItem.Value));

PopulateMenu(dtChild, int.Parse(menuItem.Value), menuItem);

}

else

{

parentMenuItem.ChildItems.Add(menuItem);

}

VB.Net

Protected Sub Page_Load(sender As Object, e As EventArgs)

If Not Me.IsPostBack Then

Dim dt As DataTable = Me.GetData(0)

PopulateMenu(dt, 0, Nothing)

End If

End Sub

Private Function GetData(parentMenuId As Integer) As DataTable

Dim query As String = "SELECT [MenuId], [Title], [Description], [Url] FROM [Menus] WHERE ParentMenuId = @ParentMenuId"

Dim constr As String = ConfigurationManager.ConnectionStrings("constr").ConnectionString

Using con As New SqlConnection(constr)

Dim dt As New DataTable()

Using cmd As New SqlCommand(query)

Using sda As New SqlDataAdapter()

cmd.Parameters.AddWithValue("@ParentMenuId", parentMenuId)

cmd.CommandType = CommandType.Text

cmd.Connection = con

sda.SelectCommand = cmd

sda.Fill(dt)

End Using

Return dt

End Using

End Function

Private Sub PopulateMenu(dt As DataTable, parentMenuId As Integer, parentMenuItem As MenuItem)

Dim currentPage As String = Path.GetFileName(Request.Url.AbsolutePath)

For Each row As DataRow In dt.Rows

Dim menuItem As New MenuItem() With { _

.Value = row("MenuId").ToString(), _

.Text = row("Title").ToString(), _

.NavigateUrl = row("Url").ToString(), _

.Selected = row("Url").ToString().EndsWith(currentPage, StringComparison.CurrentCultureIgnoreCase) _

}

If parentMenuId = 0 Then

Menu1.Items.Add(menuItem)

Dim dtChild As DataTable = Me.GetData(Integer.Parse(menuItem.Value))

PopulateMenu(dtChild, Integer.Parse(menuItem.Value), menuItem)

Else

parentMenuItem.ChildItems.Add(menuItem)

End If

End Sub

Making the ASP.Net Menu Responsive using Bootstrap

The following script needs to be placed below the ASP.Net Menu control. The following script removes the default functionality of the ASP.Net Menu control and applies the Bootstrap CSS classes to make it Responsive.

//Disable the default MouseOver functionality of ASP.Net Menu control.

Sys.WebForms.Menu._elementObjectMapper.getMappedObject = function () {

return false;

};

$(function () {

//Remove the style attributes.

$(".navbar-nav li, .navbar-nav a, .navbar-nav ul").removeAttr('style');

//Apply the Bootstrap class to the Submenu.

$(".dropdown-menu").closest("li").removeClass().addClass("dropdown-toggle");

//Apply the Bootstrap properties to the Submenu.

$(".dropdown-toggle").find("a").eq(0).attr("data-toggle", "dropdown").attr("aria-haspopup", "true").attr("aria-expanded", "false").append("<span class='caret'></span>");

//Apply the Bootstrap "active" class to the selected Menu item.

$("a.selected").closest("li").addClass("active");

$("a.selected").closest(".dropdown-toggle").addClass("active");

});

</script>

Screenshots

Desktop display
