Simple CRUD operations in ASPNet Web Forms using C and VBNet

In this article I will explain a simple tutorial with example, how to perform CRUD operations i.e. Select, Insert, Edit, Update and Delete in ASP.Net Web Forms using C# and VB.Net.

Database

I have made use of the following table Customers with the schema as follows.

Simple CRUD operations in ASP.Net Web Forms using C# and VB.Net

I have already inserted few records in the table.

Note: You can download the database table SQL by clicking the download link below.

Download SQL file

HTML Markup

The HTML Markup consists of an ASP.Net GridView placed inside AJAX UpdatePanel with multiple event handlers assigned which will be discussed later.

The GridView has a CommandField column which will display the command buttons i.e. Edit, Update, Cancel and Delete.

Below the GridView there’s a Form which will allow us to insert data to the SQL Server database table.

<asp:ScriptManager ID="ScriptManager1" runat="server">

</asp:ScriptManager>

<asp:UpdatePanel ID="UpdatePanel1" runat="server">

<asp:GridView ID="GridView1" runat="server" AutoGenerateColumns="false" OnRowDataBound="OnRowDataBound"

DataKeyNames="CustomerId" OnRowEditing="OnRowEditing" OnRowCancelingEdit="OnRowCancelingEdit" PageSize = "3" AllowPaging ="true" OnPageIndexChanging = "OnPaging"

OnRowUpdating="OnRowUpdating" OnRowDeleting="OnRowDeleting" EmptyDataText="No records has been added."

Width="450">

<asp:TemplateField HeaderText="Name" ItemStyle-Width="150">

<asp:Label ID="lblName" runat="server" Text='<%# Eval("Name") %>'></asp:Label>

</ItemTemplate>

<asp:TextBox ID="txtName" runat="server" Text='<%# Eval("Name") %>' Width="140"></asp:TextBox>

</EditItemTemplate>

</asp:TemplateField>

<asp:TemplateField HeaderText="Country" ItemStyle-Width="150">

<asp:Label ID="lblCountry" runat="server" Text='<%# Eval("Country") %>'></asp:Label>

</ItemTemplate>

<asp:TextBox ID="txtCountry" runat="server" Text='<%# Eval("Country") %>' Width="140"></asp:TextBox>

</EditItemTemplate>

</asp:TemplateField>

<asp:CommandField ButtonType="Link" ShowEditButton="true" ShowDeleteButton="true"

ItemStyle-Width="150" />

</Columns>

</asp:GridView>

<tr>

Name:<br />

<asp:TextBox ID="txtName" runat="server" Width="140" />

</td>

Country:<br />

<asp:TextBox ID="txtCountry" runat="server" Width="140" />

</td>

<asp:Button ID="btnAdd" runat="server" Text="Add" OnClick="Insert" />

</td>

</tr>

</table>

</ContentTemplate>

</asp:UpdatePanel>

</div>

Namespaces

You will need to import the following namespaces.

using System.Data;

using System.Configuration;

using System.Data.SqlClient;

VB.Net

Imports System.Data

Imports System.Configuration

Imports System.Data.SqlClient

Binding the GridView with records from SQL Database Table

The GridView is populated from the database inside the Page Load event of the page.

protected void Page_Load(object sender, EventArgs e)

{

if (!this.IsPostBack)

{

this.BindGrid();

}

private void BindGrid()

{

string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;

string query = "SELECT * FROM Customers";

using (SqlConnection con = new SqlConnection(constr))

{

using (SqlDataAdapter sda = new SqlDataAdapter(query, con))

{

using (DataTable dt = new DataTable())

{

sda.Fill(dt);

GridView1.DataSource = dt;

GridView1.DataBind();

}

VB.Net

Protected Sub Page_Load(ByVal sender As Object, ByVal e As EventArgs) Handles Me.Load

If Not Me.IsPostBack Then

Me.BindGrid()

End If

End Sub

Private Sub BindGrid()

Dim constr As String = ConfigurationManager.ConnectionStrings("constr").ConnectionString

Dim query As String = "SELECT * FROM Customers"

Using con As SqlConnection = New SqlConnection(constr)

Using sda As SqlDataAdapter = New SqlDataAdapter(query, con)

Using dt As DataTable = New DataTable()

sda.Fill(dt)

GridView1.DataSource = dt

GridView1.DataBind()

End Using

End Sub

Inserting records to GridView

The following event handler is executed when the Add Button is clicked. The name and the country values are fetched from their respective TextBoxes and then passed to the SQL Query for inserting the record in the database.

Finally the GridView is again populated with data by making call to the BindGrid method.

protected void Insert(object sender, EventArgs e)

{

string name = txtName.Text;

string country = txtCountry.Text;

txtName.Text = "";

txtCountry.Text = "";

string query = "INSERT INTO Customers VALUES(@Name, @Country)";

string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;

using (SqlConnection con = new SqlConnection(constr))

{

using (SqlCommand cmd = new SqlCommand(query))

{

cmd.Parameters.AddWithValue("@Name", name);

cmd.Parameters.AddWithValue("@Country", country);

cmd.Connection = con;

con.Open();

cmd.ExecuteNonQuery();

con.Close();

}

this.BindGrid();

}

VB.Net

Protected Sub Insert(ByVal sender As Object, ByVal e As EventArgs)

Dim name As String = txtName.Text

Dim country As String = txtCountry.Text

Dim query As String = "INSERT INTO Customers VALUES(@Name, @Country)"

Dim constr As String = ConfigurationManager.ConnectionStrings("constr").ConnectionString

txtName.Text = ""

txtCountry.Text = ""

Using con As SqlConnection = New SqlConnection(constr)

Using cmd As SqlCommand = New SqlCommand(query)

cmd.Parameters.AddWithValue("@Name", name)

cmd.Parameters.AddWithValue("@Country", country)

cmd.Connection = con

con.Open()

cmd.ExecuteNonQuery()

con.Close()

End Using

Me.BindGrid()

End Sub

Editing and Updating GridView records

Edit

When the Edit Button is clicked, the GridView’s OnRowEditing event handler is triggered. Here simply the EditIndex of the GridView is updated with the Row Index of the GridView Row to be edited.

protected void OnRowEditing(object sender, GridViewEditEventArgs e)

{

GridView1.EditIndex = e.NewEditIndex;

this.BindGrid();

}

VB.Net

Protected Sub OnRowEditing(sender As Object, e As GridViewEditEventArgs)

GridView1.EditIndex = e.NewEditIndex

Me.BindGrid()

End Sub

Update

When the Update Button is clicked, the GridView’s OnRowUpdating event handler is triggered.

CustomerId which is the primary key is fetched from the DataKey property of GridView while the Name and Country fields are fetched from their respective TextBoxes and are passed to the SQL Query for updating the records in the database.

Note: For more details on DataKeys please refer my article DataKeyNames in GridView example in ASP.Net.

Finally the GridView is again populated with data by making call to the BindGrid method.

protected void OnRowUpdating(object sender, GridViewUpdateEventArgs e)

{

GridViewRow row = GridView1.Rows[e.RowIndex];

int customerId = Convert.ToInt32(GridView1.DataKeys[e.RowIndex].Values[0]);

string name = (row.FindControl("txtName") as TextBox).Text;

string country = (row.FindControl("txtCountry") as TextBox).Text;

string query = "UPDATE Customers SET Name=@Name, Country=@Country WHERE CustomerId=@CustomerId";

string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;

using (SqlConnection con = new SqlConnection(constr))

{

using (SqlCommand cmd = new SqlCommand(query))

{

cmd.Parameters.AddWithValue("@CustomerId", customerId);

cmd.Parameters.AddWithValue("@Name", name);

cmd.Parameters.AddWithValue("@Country", country);

cmd.Connection = con;

con.Open();

cmd.ExecuteNonQuery();

con.Close();

}

GridView1.EditIndex = -1;

this.BindGrid();

}

VB.Net

Protected Sub OnRowUpdating(ByVal sender As Object, ByVal e As GridViewUpdateEventArgs)

Dim row As GridViewRow = GridView1.Rows(e.RowIndex)

Dim customerId As Integer = Convert.ToInt32(GridView1.DataKeys(e.RowIndex).Values(0))

Dim name As String = (TryCast(row.FindControl("txtName"), TextBox)).Text

Dim country As String = (TryCast(row.FindControl("txtCountry"), TextBox)).Text

Dim query As String = "UPDATE Customers SET Name=@Name, Country=@Country WHERE CustomerId=@CustomerId"

Dim constr As String = ConfigurationManager.ConnectionStrings("constr").ConnectionString

Using con As SqlConnection = New SqlConnection(constr)

Using cmd As SqlCommand = New SqlCommand(query)

cmd.Parameters.AddWithValue("@CustomerId", customerId)

cmd.Parameters.AddWithValue("@Name", name)

cmd.Parameters.AddWithValue("@Country", country)

cmd.Connection = con

con.Open()

cmd.ExecuteNonQuery()

con.Close()

End Using

GridView1.EditIndex = -1

Me.BindGrid()

End Sub

Cancel Edit

When the Cancel Button is clicked, the GridView’s OnRowCancelingEdit event handler is triggered. Here the EditIndex is set to -1 and the GridView is populated with data.

protected void OnRowCancelingEdit(object sender, EventArgs e)

{

GridView1.EditIndex = -1;

this.BindGrid();

}

VB.Net

Protected Sub OnRowCancelingEdit(sender As Object, e As EventArgs)

GridView1.EditIndex = -1

Me.BindGrid()

End Sub

Deleting GridView records

When the Delete Button is clicked, the GridView’s OnRowDeleting event handler is triggered.

CustomerId which is the primary key is fetched from the DataKey property of GridView and is passed to the SQL Query for deletion of the record from the database.

Finally the GridView is again populated with data by making call to the BindGrid method.

protected void OnRowDeleting(object sender, GridViewDeleteEventArgs e)

{

int customerId = Convert.ToInt32(GridView1.DataKeys[e.RowIndex].Values[0]);

string query = "DELETE FROM Customers WHERE CustomerId=@CustomerId";

string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;

using (SqlConnection con = new SqlConnection(constr))

{

using (SqlCommand cmd = new SqlCommand(query))

{

cmd.Parameters.AddWithValue("@CustomerId", customerId);

cmd.Connection = con;

con.Open();

cmd.ExecuteNonQuery();

con.Close();

}

this.BindGrid();

}

VB.Net

Protected Sub OnRowDeleting(ByVal sender As Object, ByVal e As GridViewDeleteEventArgs)

Dim customerId As Integer = Convert.ToInt32(GridView1.DataKeys(e.RowIndex).Values(0))

Dim query As String = "DELETE FROM Customers WHERE CustomerId=@CustomerId"

Dim constr As String = ConfigurationManager.ConnectionStrings("constr").ConnectionString

Using con As SqlConnection = New SqlConnection(constr)

Using cmd As SqlCommand = New SqlCommand(query)

cmd.Parameters.AddWithValue("@CustomerId", customerId)

cmd.Connection = con

con.Open()

cmd.ExecuteNonQuery()

con.Close()

End Using

Me.BindGrid()

End Sub

In order to display a confirmation message when deleting row, I have made use of OnRowDataBound event handler where I have first determined the Delete Button and then I have attach the JavaScript Confirm to its client side Click event handler.

protected void OnRowDataBound(object sender, GridViewRowEventArgs e)

{

if (e.Row.RowType == DataControlRowType.DataRow && e.Row.RowIndex != GridView1.EditIndex)

{

(e.Row.Cells[2].Controls[2] as LinkButton).Attributes["onclick"] = "return confirm('Do you want to delete this row?');";

}

VB.Net

Protected Sub OnRowDataBound(sender As Object, e As GridViewRowEventArgs)

If e.Row.RowType = DataControlRowType.DataRow AndAlso e.Row.RowIndex <> GridView1.EditIndex Then

TryCast(e.Row.Cells(2).Controls(2), LinkButton).Attributes("onclick") = "return confirm('Do you want to delete this row?');"

End If

End Sub

Paging

The OnPageIndexChanging event handler is triggered when a Page Number is clicked. Here, the PageIndex property of the GridView is updated.

Finally the GridView is again populated with data by making call to the BindGrid method.

protected void OnPaging(object sender, GridViewPageEventArgs e)

{

GridView1.PageIndex = e.NewPageIndex;

this.BindGrid();

}

VB.Net

Protected Sub OnPaging(ByVal sender As Object, ByVal e As GridViewPageEventArgs)

GridView1.PageIndex = e.NewPageIndex

Me.BindGrid()

End Sub

Displaying AJAX Loader during Add, Edit, Update, Delete and Paging operations

The jQuery BlockUI Plugin has been applied to the dvGrid HTML DIV. When the ASP.Net AJAX UpdatePanel makes a request, the HTML DIV is blocked and an animation is displayed.

When the request is completed, the HTML DIV is unblocked and the animation is hidden.

$(function () {

BlockUI("dvGrid");

$.blockUI.defaults.css = {};

});

function BlockUI(elementID) {

var prm = Sys.WebForms.PageRequestManager.getInstance();

prm.add_beginRequest(function () {

$("#" + elementID).block({ message: '<div align = "center">' + '<img src="images/loadingAnim.gif"/></div>',

css: {},

overlayCSS: { backgroundColor: '#000000', opacity: 0.6, border: '3px solid #63B2EB' }

});

prm.add_endRequest(function () {

$("#" + elementID).unblock();

});

};

</script>

Screenshot

Downloads

Download Code

Simple CRUD operations in ASP.Net Web Forms using C# and VB.Net
