This article I will explain with an example, how to implement Select2 DropDownList using jQuery AJAX in ASP.Net Core (.Net Core 7) MVC.
Note: For beginners in ASP.Net Core (.Net Core 7), please refer my article ASP.Net Core 7: Hello World Tutorial with Sample Program example.



Select2 plugin

Please refer the following link for documentation for the jQuery Select2 plugin
https://www.jsdelivr.com/package/npm/select2



Database

I have made use of the following table Customers with the schema as follows.
ASP.Net Core: Select2 DropDownList using jQuery Ajax

I have already inserted few records in the table.
ASP.Net Core: Select2 DropDownList using jQuery Ajax

Note: You can download the database table SQL by clicking the download link below.
           Download SQL file



Model

The Model class consists of following properties.
public class Customer
{
    [Key]
    public int CustomerId { get; set; }
    public string Name { get; set; }
}



Database Context

Once the Entity Framework is configured and connected to the database table, the Database Context will look as shown below.
Note: For beginners in ASP.Net Core and Entity Framework, please refer my article ASP.Net Core 7: Simple Entity Framework Tutorial with example. It covers all the information needed for connecting and configuring Entity Framework with ASP.Net Core.

using Microsoft.EntityFrameworkCore;

namespace MultiSelect_DropDown_jQuery_MVC_Core
{
    public class DBCtx : DbContext
    {
        public DBCtx(DbContextOptions<DBCtx> options) : base(options)
        {
        }

        public DbSet<CustomerModel> Customers { get; set; }
    }
}



Controller

The Controller consists of following Action methods.

Action method for handling GET operation

Inside this Action method, simply the View is returned.


Action method for handling jQuery AJAX operation

This Action method handles the call made from the jQuery AJAX function from the View.
Note: The following Action method handles AJAX calls and hence the return type is set to JsonResult.
          For more details on JsonResult in Core MVC, please refer my article ASP.Net Core: Return JSON from Controller in ASP.Net Core MVC.

This method accepts the value of the INPUT TextBox from the View as parameter.
Then, a Generic List of CustomerModel class object is created based on the TextBox value the related Customers Name are fetched using Entity Framework and returned as JSON result.


Action method for handling POST operation

The Action method accepts CustomerModel class object as parameter.
Inside this Action method, the Name and CustomerId values of the selected Customer are fetched using EntityFramework and set into a ViewBag object which will be later displayed used in View for displaying JavaScript Alert MessageBox.
public class HomeController : Controller
{
    private DBCtx Context { get; }
    public HomeController(DBCtx _context)
    {
        this.Context = _context;
    }

    public IActionResult Index()
    {
        return View();
    }

    [HttpGet]
    public JsonResult GetCustomers(string searchTerm)
    {
        List<CustomerModel> data = this.Context.Customers.Where(c => c.Name.ToUpper().Contains(searchTerm)).ToList();
        return new JsonResult(data);
    }

    [HttpPost]
    public IActionResult Index(CustomerModel model)
    {
        CustomerModel customer = this.Context.Customers.ToList().Find(p => p.CustomerId == model.CustomerId);
        ViewBag.Message += "Name: " + customer.Name;
        ViewBag.Message += "\\nID: " + customer.CustomerId;
        return View(customer);
    }
}



View

HTML Markup

Inside the View, the ASP.Net TagHelper is inherited and CustomerModel class is declared as model for the View.
The View consists of an HTML Form which has been created using the following TagHelpers attributes.
asp-action – Name of the Action. In this case the name is Index.
asp-controller – Name of the Controller. In this case the name is Home.
method – It specifies the Form Method i.e. GET or POST. In this case it will be set to POST.
The Form consists of a DropDownList and a Submit Button.


Implementing Select2 DropDownList plugin

Inside the HTML Markup, the following CSS script file is inherited.
1. select2.min.css
Then, the following script files are inherited.
1. jquery.min.js
2. select2.min.js
Inside the jQuery document ready event handler, the select2 plugin is applied to the HTML SELECT element.


Properties:

minimumInputLength – it defines the minimum number of characters the user must type before a search is performed.
Then, a jQuery AJAX call is made to the GetCustomers Action method and serach item is sent to the server.


Event Handlers:

processResults – When response is get from server, this event handler is triggered. This event handler processes the response from Action result method before displaying it in the dropdown.


Submitting the Form

When the Submit Button is clicked, the Form gets submitted and the CustomerId of the selected Customer is sent to the Controller.
Finally, the Name and ID value of the selected Customer is displayed using JavaScript Alert MessageBox.
@addTagHelper*, Microsoft.AspNetCore.Mvc.TagHelpers
@model MultiSelect_DropDown_jQuery_MVC_Core.Models.CustomerModel
@{
    Layout = null;
}

<!DOCTYPE html>

<html>
<head>
    <meta name="viewport" content="width=device-width" />
    <title>Index</title>
</head>
<body>
    <form method="post" asp-controller="Home" asp-action="Index">
        Name:
        <select id="ddlCustomers" asp-for="CustomerId" style="width:300px"></select>
        <br />
        <br />
        <input type="submit" value="Submit" />
        @if (ViewBag.Message != null)
        {
            <script type="text/javascript">
                window.onload = function () {
                    alert("@ViewBag.Message");
                };
            </script>
        }
        <script type="text/javascript" src="https://cdnjs.cloudflare.com/ajax/libs/jquery/3.7.1/jquery.min.js"></script>
        <link href="https://cdn.jsdelivr.net/npm/select2@4.0.13/dist/css/select2.min.css" rel="stylesheet"/>
        <script src="https://cdn.jsdelivr.net/npm/select2@4.0.13/dist/js/select2.min.js"></script>
        <script type="text/javascript" >
            $(function () {
                $('#ddlCustomers').select2({
                    minimumInputLength: 1,
                    ajax: {
                        url: '/Home/GetCustomers',
                        dataType: 'json',
                        data: function (params) {
                            return { searchTerm: params.term }
                        },
                        processResults: function (data) {
                            return {
                                results: $.map(data, function (item) {
                                    return {
                                        id: item.CustomerId,
                                        text: item.Name
                                    };
                                })
                            };
                        }
                    }
                });
            });
        </script>
    </form>
</body>
</html>



Screenshot

ASP.Net Core: Select2 DropDownList using jQuery Ajax



Demo

View Demo



Downloads

Download Code
