In this article I will explain with an example, how to pass parameter to Stored Procedure using Dapper library in Windows Forms (WinForms) Application using C# and VB.Net.



Installing Dapper package using Nuget

In order to install Dapper library using Nuget, please refer my article Install Dapper from Nuget in Visual Studio.



Database

I have made use of the following table Customers with the schema as follows.
Pass parameter to Stored Procedure using Dapper in C# and VB.Net

I have already inserted few records in the table.
Pass parameter to Stored Procedure using Dapper in C# and VB.Net

Note: You can download the database table SQL by clicking the download link below.
          Download SQL file



Stored Procedure

The following Stored Procedure is used to display the records from SQL Server database.
This Stored Procedure accepts Country as a parameter, which is used to display the records from Customers Table.
CREATE PROCEDURE [Customers_GetCustomersByCountry]
      @Country VARCHAR(50)
AS
BEGIN
    SET NOCOUNT ON;
    SELECT [CustomerId]
          ,[Name]
          ,[Country]
    FROM [Customers]
    WHERE [Country] = @Country
END



Form Design

The Form consists of following controls:
Label – For labelling the controls.
ComboBox – For selecting Country name.
Button – For displaying records.
The Button has been assigned with a Click event handler.
DataGridView – For displaying data.
Pass parameter to Stored Procedure using Dapper in C# and VB.Net



Namespaces

You will need to import the following namespaces.
C#
using Dapper;
using System.Data;
using System.Data.SqlClient;
using System.Configuration;

VB.Net
Imports Dapper
Imports System.Data
Imports System.Data.SqlClient
Imports System.Configuration



Pass Parameter with Stored Procedure using Dapper in C# and VB.Net

Inside the Form Load event handler, the ComboBox items are added.
When the Search button is clicked, the IDataReader class object is created where the ExecuteReader method is called.
Then, the name of the Stored Procedure and the Country value is passed to the ExecuteReader method of the Dapper library which then copied to DataTable object using Load method.
Note: For more details on ExecuteReader method, please refer my article Understanding Dapper ExecuteReader in C# and VB.Net.

Finally, DataTable is assigned to the DataSource property of DataGridView.
C#
private void Form1_Load(object sender, EventArgs e)
{
    cbCountries.Items.Add("United States");
    cbCountries.Items.Add("India");
    cbCountries.Items.Add("France");
    cbCountries.Items.Add("Russia");
}

private void OnSearch(object sender, EventArgs e)
{
    string country = cbCountries.SelectedItem.ToString();
    string spName = "Customers_GetCustomersByCountry";
    string constr = ConfigurationManager.ConnectionStrings["constr"].ConnectionString;
    using (SqlConnection con = new SqlConnection(constr))
    {
        using (IDataReader sdr = con.ExecuteReader(spName, new { country }, commandType: CommandType.StoredProcedure))
        {
            using (DataTable dtCustomers = new DataTable())
            {
                dtCustomers.Load(sdr);
                dgvCustomers.DataSource = dtCustomers;
            }
        }
    }
}

VB.Net
Private Sub Form1_Load(sender As Object, e As EventArgs) Handles MyBase.Load
    cbCountries.Items.Add("United States")
    cbCountries.Items.Add("India")
    cbCountries.Items.Add("France")
    cbCountries.Items.Add("Russia")
End Sub

Private Sub OnSearch(sender As Object, e As EventArgs) Handles btnSearch.Click
    Dim country As String = cbCountries.SelectedValue.ToString()
    Dim spName As String = "Customers_GetCustomersByCountry"
    Dim constr As String = ConfigurationManager.ConnectionStrings("constr").ConnectionString
    Using con As SqlConnection = New SqlConnection(constr)
        Using sdr As IDataReader = con.ExecuteReader(spName, New With {country}, commandType:=CommandType.StoredProcedure)
            Using dtCustomers As DataTable = New DataTable()
                dtCustomers.Load(sdr)
                dgvCustomers.DataSource = dtCustomers
            End Using
        End Using
    End Using
End Sub



Screenshot

Pass parameter to Stored Procedure using Dapper in C# and VB.Net
